Automatic Sorting Trainer Robot Trainer
Description & Specification
Automatic Sorting Trainer Robot Trainer
Categories:
Electrical Training Equipment Products
Technical Specifications
Functions:
Easy cabling-using one single flat cable to connect dsPIC Microcontroller Unit.
Its portable size makes it easy to carry out experiments on lab table.
The status of input and output signals are monitored and displayed on nearby status LED.
dsPIC Microcontroller Unit
Functions:
The trainer is protected by a suitcase for easy carrying and storage.
The pins of MCU are protected by photo coupler.
This unit includes a dsPIC30F4011 chip and peripheral I/O circuits, which is very helpful to understand the knowledge related with microprocessor control.
Able to use either TACT or Slide switch as signal input.
48K byte program memory or above
2K byte RAM or aljove AC power switch
6-Bit digital signal controller
40 Pins or above
Reset TACT switch MCU Power LED Input:
Slide switch X14
TACT switch X14
Input: minimum AC90~264V, 47~63Hz
Output :minimum DC 5V/2.5A, DC 3.3V/2.5A, 24V/2A
Photocoupler IC X14 Output:
Indicator LED X10
Photocoupler IC X10 Power
Indicator LED X14
Automatic Sorting Robot
Functions:
DC motor control, various sensors, pneumatic cylinder control, position control and detection for sliding table, C code programming practice
Abundant experimental practices
Widespread control applications
Suitable for MCU beginners
Systematic training for trainees.
