Electrical Motor and Transformer Trainer
Description & Specification
Electrical Motor and Transformer Trainer
Categories:
Electrical Training Equipment Products
Technical Specifications
This trainer include various types of inductive motors and control components, through experiments students can be familiar with AC motor features, master its control principles and control mode, it will cultivate students' technical skills and knowledge.
Character:
Equipped with motors, students can make combination, and finish many training contents.
Training workbench has high safety system.
Training workbench use aluminum column structure frame, it include meter box and power box to test and measure technical parameter, it is easy to use and it is not easy to be broken.
Technical Parameter:
Whole capacity:<2.0KVA
Input power: single phase, three wires, 380V±10% 50Hz
Work environment:
Environment temperature: -10ºC~+40ºC
Relative humidity: <85%(25ºC)
Dimension: 1600mm×800mm×1300mm
Weight: <200kg
Product consist of:
Power control panel:
Power control panel use aluminum structure metal panel, all close type boxes structure
Training workbench:
The workbench panel thick is 25mm high density substrate , there is high temperature high pressure anti-fire treatment process. Training workbench use aluminum structure. There are universal 4 wheels at the bottom of workbench, there are 2 breakers on wheel. The trainer can be moved or stop convenient. It equip with three guide rail type drawer, 2 push and plug cabinet. The structure is sound and reliable, outlook is beautiful.
Power control panel:
Equipment with power indicator, Europe socket output plug, 4mm safety power output sockets.
Equipment with AC motor protection switch, inner with AC power supply, with short circuit protection function.
Three phases, five wires power input, it has been tested by leakage breaker control, it has emergency stop button, you can cut off electricity when emergency.
