Experiments With An Axial Fan
Description & Specification
Experiments With An Axial Fan
Categories:
Fluid Mechanics Teaching Equipment
Technical Specifications
Features an axial fan with variable speed via an integrated controller, an intake pipe and a delivery pipe. The transparent intake and delivery pipes are fitted with guide plates for flow guidance. A flow straightener in the intake pipe serves to calm the air. The air flow is adjusted by a throttle valve at the end of the delivery pipe.
The experimental unit provides the basic experiments to get to know the operating behaviour and the important characteristic variables of axial fans.
The medium to be transported is drawn in axially to the drive shaft of the axial fan by the rotation of the rotor. The medium flows through the rotor and is discharged axially behind the rotor.
Specification:
Functioning and operating behaviour of an axial fan
Throttle valve to adjust the air flow in the delivery pipe
Determination of flow rate
Due to integrated microprocessor-based instrumentation no additional devices with error-prone wiring are required
Axial fan with electronically commutated drive motor
Variable speed via integrated controller
Transparent intake and delivery pipes
Display of differential pressure, flow rate, speed, electrical power consumption and hydraulical power output, temperature and efficiency.
Technical data:
Axial fan
Power consumption: 90W
Nominal speed: 9500min-1
Max. volumetric flow rate: approx. 600m3/h
Max. pressure difference: approx. 700Pa
Delivery pipe
Inner diameter: 110mm
Length: 310mm
Intake pipe
Inner diameter: 110mm
Length: 275mm
Measuring ranges
Differential pressure: 0…1800Pa
Speed: 0…9999min-1
Flow rate: 0…1000m3/h
Temperature: 0…100°C
Power consumption: 0…500W
230V, 50Hz, 1 phase
230V, 60Hz, 1 phase; 120V, 60Hz, 1 phase.
