Flow Meter Demonstration Apparatus

Product Code LTEKCTLB-FMT61-0053

Description & Specification

Flow Meter Demonstration Apparatus

Enquire Now Print Page

Categories: Fluid Mechanics Teaching Equipment

Tags: Flow Meter Demonstration Apparatus

Technical Specifications

Purpose – To enable students to introduce the three types of flow meters.

Ordering Specification

Pressure tappings to measure head loss from each meter

Supplied with manometer board with eight tubes

Quick release fitting for easy connection to hydraulics bench

Venturi meter, variable area meter and orifice plate with control valve

This accessory is designed to introduce students to three basic types of flow meter.

Demonstration Capabilities

Calibrating each flow meter using the volumetric measuring tank of the bench

Comparing pressure drops across each device

Directly comparing flow measurement using a Venturi meter, variable area meter and orifice plate

Technical Detail

Orifice plate diameter: 20mm

Variable area meter: 2.66to 26.66 litres/min

Manometer range: 0 to 400mm

Number of manometer tubes: 8

Venturi dimensions:

Upstream pipe diameter 25mm

Upstream taper 210inclusive

Throat diameter 9mm

Downstream taper 80 inclusive.
