Heat Transfer Bench
Description & Specification
Heat Transfer Bench
Categories:
Thermal Training Equipment
Technical Specifications
This product is an extensible educational experiment equipment for students to observe the heating, cooling and air movement of the device during operation. Students can observe the mixing of air and conduct tests to monitor temperature and air pressure. Grasp its control principle and control method, cultivate students’ corresponding knowledge and skills, suitable for higher vocational schools, engineering university, secondary vocational school and technical school related professional teaching and skills training evaluation.
Features:
The training platform has a good safety protection system.
The desktop uses a 25mm thick high-density substrate, and the surface is treated with high-temperature and high-pressure fire-resistant panels. The structure is firm and beautiful. The training platform adopts an aluminum column frame structure with a universal wheel at the bottom for flexible movement. The instrument and power supply are integrated and installed, which is easy to use and not easily damaged.
Technical Specifications:
Overall capacity: <2.5KVA
Input Power: AC220V±10% 60Hz
Fan: Supply voltage: AC220V/50Hz Power: 1.5kW; Maximum flow rate: 2.160m3/h
Working conditions: Ambient temperature -10°C to +40°C Relative humidity <85% (25°C)
Overall dimensions: 2000mm x 750mm x 2100mm
Weight: <100kg
Product Introduction:
Power control panel
The power control panel adopts an aluminum alloy frame and a closed box structure, which is integrated with the placement rack below.
The power input is controlled by the leakage breaker and the emergency stop control button is provided. In case of emergency, you press emergency stop button is so as to cut off the power.
Configured with circuit breaker, power indicator, temperature adjustment knob, thermometer, power socket, differential pressure gauge, thermostat and intelligent electrical parameter measuring instrument.
