Multi PLC Training Panel PLC Trainer Kit
Description & Specification
Multi PLC Training Panel PLC Trainer Kit
Categories:
Electrical Training Equipment Products
Technical Specifications
Main Functions:
Can finish PLC commonly used programming instructions learning and training, PLC typical application project training, PLC control car linear motion project training, PLC control three-phase asynchronous motor running project training. Have a safety protection function.
Basic experiments
1. PLC basic instruction practice training:
2. PLC project training:
1) Beacon lights twinkle circle
2) Eight-bit code display to show numbers
3) Automatic mail sorting
4) Automatic cistern water level control
5) Tool Choice control of machining center
6) Automatic immixture of multi kinds of liquid control
7) Automatic moulding machine
8) Automatic assembly line control
9) Automatic rolling mill control
10)Traffic lights control
11) Manipulator motion control
12) Automatic material transport and beading f control
13) PLC control of motor running/stopping
14) PLC control of motor jogging self-locking
15) PLC control of motor forward/reverso rotation
16) PLC control of motor delt-star start.
17) PLC control of step motor
Technical Specification:
Dimension: 1600mm-1700mm x 650mm for training panel
The total dimension is 750mm x 1450mm-1550 mm
Working power: Three-phase AC380V-410V, power < 500 VA.
