Open Channel Flow Demonstration Apparatus

Product Code LTEKCTLB-FMT61-0054

Description & Specification

Open Channel Flow Demonstration Apparatus

Enquire Now Print Page

Categories: Fluid Mechanics Teaching Equipment

Tags: Open Channel Flow Demonstration Apparatus

Technical Specifications

Purpose – To introduce the characteristics of flow in an open channel at an elementary level for the students.

Ordering Specification:

The Flow Channel introduces students to the characteristics of flow in an open channel at an elementary level.

Clear acrylic working section fed from stilling tank

Quick release fitting for easy connection to hydraulics bench

Dye injection system

Six different models for investigation

Demonstration Capabilities:

Visualization of flow patterns over or around immersed objects

Demonstrating basic phenomena associated with open channel flow

Technical Detail:

Dye reservoir capacity: 0.45 litres

Width of channel: 15mm

Length of channel: 615mm

Depth of channel: 150mm

Dye injection needles: 5

Models: – broad crested weir

Narrow crested weir

Small cylinder

Large cylinder

Symmetrical aerofoil

Asymmetrical aerofoil.
