Surface Grinding Machine

Product Code LTEKCTLB-WK05-1032

Description & Specification

Surface Grinding Machine

Machine s bed has unique design in which the Table and the Upright are aligned exactly at right angles.
Saddle is guided on ground V-ways resting for high precision and smooth operations.
Wheel Head is mounted on a constructed vertically column supported by Preloaded precision bearings. Driving pulleys are dynamically balanced.

Max. Table Size (mm)	200 x 450		300 x 450	200 x 600	300 x 600
Max. Longitudinal Travel (mm)	525		525	675	675
Max. Cross Travel (mm)	240		350	240	350
Max. Spindle Center Height above Table (mm)	400		400	400	750
SPEED AND FEEDS
Max. Table Speed (m/min)		15	1.5 to 15	1.5 to 18	1.5 to 18
Power Cross Traverse (m/min)		1000	1000	1000	1000
Auto Cross Feed at each Table reversal (infinitely variable) (mm)		0.5 to 10	0.5 to 10	0.5 to 10	0.5 to 10
Least Count of vertical feed head wheel (mm)		0.002	0.002	0.002	0.002
GRINDING HEAD
Size of Grinding wheel (mm)		200 x 20 x 31.75	200 x 20 x 31.75	250 x 25 x 76.2	250 x 25 x 76.2
Power of spindle motor (HP)		2	2	3	3
Speed of grinding spindle (RPM)		2800	2800	2800	2800
HYDRAULIC SYSTEM
Working Pressure (Kg/cm)		20	20	20	20
Motor (HP)		2	2	2	2
Tank capacity (Ltrs)		75	75	75	75

Trusted Surface Grinding Machine Manufacturer & Supplier

LTekOnline are the manufacturers of Surface Grinding Machine used to demonstrate engineering principles in Engineering Colleges, Engineering Schools, and Workshop Machines for Engineering Teaching Lab in Universities. We supply Surface Grinding Machine to TVET institutes, vocational training centres, polytechnics and research labs across more than 90 countries, with quality testing technology, comprehensive operation manuals and full after-sales support.

Manufactured to international standards

Detailed operation & experiment manuals

Turnkey lab installation & training

Worldwide shipping & on-site support
