Temperature Control Bench

Product Code LTEKCTLB-TTE60-0055

Description & Specification

Temperature Control Bench

Enquire Now Print Page

Categories: Thermal Training Equipment

Tags: Temperature Control Bench

Technical Specifications

Teaching Objectives :

Study and adjust a temperature control loop

Study and parameterization of a PID controller

The bench includes :

An oven with thermal protection by perforated stainless steel plate including :

Platinum probe type Pt100

Single-phase power dimmer 25A 4-20 mA.

Heating resistance 95 W

Safety thermocouple

Temperature transmitter: Pt100 converter 0 – 400°C, 4-20 mA

PID regulator

A fan for hot/cold regulation or the creation of a disturbance.

Safety thermostat TCK/J set at 350°C Electrical box including:

A configurable electronic PID controller.

A pad lockable disconnecting switch for powering up the box.

Disturbance on/off switch

A 240V/50Hz socket for recorder

Fan on/off switch

Signals available on ø4 safety plugs Installation:

Services and supplies required for the installation: installation and installation, power supply of the installations, start-up and testing.
