Training Bench Of Flow And Level Control

Product Code LTEKCTLB-FMT61-00189

Description & Specification

Training Bench Of Flow And Level Control

Features:

The experimental circuit and devices are fully configured and can be used in combination to complete the training contents of a variety of subjects.

The training platform has a good security system.

Training adopts aluminum frame type structure, the control object and actuators integrated installation, practical circuit and device adopts security terminal adapter, each unit with flexible, easy to use, not easy to damage.

Performance Parameters:

Unit capacity: < 1KVA

Input power: 230V plus or minus 10% 50Hz

External dimensions: 600mm x 500mm x 1600mm

Working conditions: temperature – 10 ? ~ + 40 ? relative humidity < 85% (25 ?)

Weight: < 60kg

Control system

Using transparent acrylic water column, the liquid level change can be observed with the liquid level sensor and flow sensor.

The control system adopts Siemens PLC and PID controller, which can be controlled by configuration software.

Control objects

Power supply configuration

Equipped with power indicator, European power output socket and secure type power supply terminal.

Built-in ac power, with short circuit protection.

Built-in dc power, with short circuit protection.

Single phase three-wire power supply input, through leakage circuit breaker control output, with emergency stop control button, press the emergency stop button breaker to cut off the power.

Supporting Devices

The cylindrical transparent water tank 4 piece

1 piece transparent storage tank

Solenoid valve 4 piece

1 piece water pump

Flow sensor 1 piece

Liquid level sensor 4 piece

Water level switch 4 piece

PLC module 1 piece

PID controller 2 piece

1 set of programming software (teaching edition)

Pipe fittings and joint sets

Complete training contents

Liquid level control experiment

The configuration control experiment of liquid level and flow

Comprehensive control experiment of liquid level and flow of water tank

Flow control experiment

Application of industrial controller.

Liquid level and flow control experiment of open loop and closed loop

Liquid level and flow cascade regulation experiment

P,PI,PID control experiment.
