Training System: Temperature Control

Product Code LTEKCTLB-FMT61-0082

Description & Specification

Training System: Temperature Control

Enquire Now Print Page

Categories: Fluid Mechanics Teaching Equipment

Tags: Training System: Temperature Control

Technical Specifications

Experimental unit for control engineering experiments

Heating and cooling by Peltier element

Process schematic on front panel

Temperature control of a heated metal bar

Temperature sensors at 3 different points along axis of bar to establish thermal lags.

Technical Data

Heated bar: DxL: 20x200mm, aluminium

Peltier element

Power consumption depending on temperature

Power at 50°c: 44,3w

Power at 300k: 38,2w

Operated by dc voltage

Fan

Power consumption: 2W

Max. Flow rate: 40m³/h

Thermometer: 0…100°C

Temperature sensor: 0…100°C

Temperature control range: 0…100°C

Process schematic with controller type selection (manual, continuous controller, two- or three-point controller, programmer)

Time functions

Simulation function

Disturbance variable input

Dimensions and Weight

LxWxH: 600x450x260mm

Weight: approx. 16kg.
