Trinocular LED Dual View Teaching Histopathology Teaching Microscope

Eyepiece: Focusable 10x/22mm widefield eyepieces with foldable eye guards, antifungal coated
Nosepiece: Reverse angle quintuple nosepiece (Ball bearing type) with click stops and rubber grip
Stand: Single mold sturdy stand with anti rust materials. Extended base for better stability
Main Viewing Body: Trinocular 30° inclined, 360° rotatable, Inter-pupillary distance 47 - 75mm with height adjustment
Dual view Attachment: Dual view bridge with Binocular Observation Head, WF 10x/20mm eyepieces, illuminated LED pointer and 100V-240V AC power adapter
Condenser: Flip-top sub stage Abbe condenser NA 1.25 with aspheric lens. Iris diaphragm with blue day light filter. Rack and pinion movements on stainless steel guides
Focusing: Co-axial coarse and fine focusing on gear systems for smooth operation. Fine adjustment 0.3mm/rotation
Illumination: LED illumination with intensity, built-in rechargeable battery for cordless operation. LED lamp life is up to 100,000 hours
Electrical: Universal input 100V - 240V AC, 50/60 Hz. Built-in voltage stabilizer
Objectives: Series Infinity Corrected DIN Plan Achromatic objectives 2.5x, 4x, 10x, 20x, 40x (spring loaded), antifungal coated
Mechanical stage: Rackless X-axis Ceramic double plate stage, size 200 x 160mm, X/Y travel range 76mm x 50mm. Double specimen holder
