Eyepiece: Focusable 10x/22mm widefield eyepieces with foldable eye guards, antifungal coated
Nosepiece: Reverse angle quintuple nosepiece (Ball bearing type) with click stops and rubber grip
Stand: Single mold sturdy stand with anti rust materials. Extended base for better stability
Main Viewing Body: Trinocular 30° inclined, 360° rotatable, Inter-pupillary distance 47 - 75mm with height adjustment
Dual view Attachment: Dual view bridge with Binocular Observation Head, WF 10x/20mm eyepieces, illuminated LED pointer and 100V-240V AC power adapter
Condenser: Flip-top sub stage Abbe condenser NA 1.25 with aspheric lens. Iris diaphragm with blue day light filter. Rack and pinion movements on stainless steel guides
Focusing: Co-axial coarse and fine focusing on gear systems for smooth operation. Fine adjustment 0.3mm/rotation
Illumination: LED illumination with intensity, built-in rechargeable battery for cordless operation. LED lamp life is up to 100,000 hours
Electrical: Universal input 100V - 240V AC, 50/60 Hz. Built-in voltage stabilizer
Objectives: Series Infinity Corrected DIN Plan Achromatic objectives 2.5x, 4x, 10x, 20x, 40x (spring loaded), antifungal coated
Mechanical stage: Rackless X-axis Ceramic double plate stage, size 200 x 160mm, X/Y travel range 76mm x 50mm. Double specimen holder

Microscope School Lab Equipment Suppliers in India

Ltekonline are the manufacturers of Trinocular LED Dual View Teaching Histopathology Teaching Microscope used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and School Microscope for Engineering Teaching Lab in Universities
