Objectives: Infinity Plan achromat, anti-fungal 4X, 10X, 40X, 100X
Focusing: Stage height movement (coarse movement stroke: 15 mm ), Stroke per rotation for coarse adjustment knob: 36.8 mm, Focusing stopper, Torque adjustment for coarse adjustment knob, Fine focus knob (minimum adjustment gradations: 2.5 μm)
Viewing Head: 30° inclined trinocular tube (anti-fungal), eyepiece/camera port = 100/0 or 0/100, Interpupillary distance: 48-75 mm, Eyepoint adjustment: 375.0-427.9 mm
Optical System: Infinity optical system
Observation Methods: Brightfield, darkfield
Eyepieces (anti-fungal): 10X Field Number (FN): 20
Revolving Nosepiece: Fixed quadruple nosepiece with inward tilt
Stage: Wire movement mechanical fixed stage 211 mm x 154 mm, Traveling range: 76 mm x 52 mm, Single specimen holder Stage XY movement stopper
Condenser: Abbe condenser NA 1.25 with oil immersion, Built-in aperture iris diaphragm
Illumination System: Built-in transmitted illumination system, illumination (fixed field diaphragm), LED power consumption 2.4 W (nominal value), precentered

Microscope School Lab Equipment Suppliers in India

Ltekonline are the manufacturers of Trinocular Microscope Laboratory Microscope used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and School Microscope for Engineering Teaching Lab in Universities
