Universal Milling Machine
Description & Specification
Technical Specifications
Universal milling machine includes a horizontal arbor for horizontal milling, slotting and keyway cutting. The machine is useful for mechanic workshops, production, training, single-part manufacturing and prototyping. Featuring both horizontal and vertical spindles, it is said to combine the flexibility of running a standard vertical mill with the performance required to accommodate various complex applications.
Other features include outboard support, a vibration-damping, cast iron construction, automatic and rapid feeds in all three axes as well as three-axis. The 2-hp machine provides a different table area for long travel distances along with a 45-degree vertical swivel head for additional flexibility.
Equipped with adjustable, ground dovetail guideways on the X axis and wide, square guideways on the Y and Z axes, the machine includes adjustable stops for drilling depth and table adjustments. Standard equipment includes a position indicator, a coolant system, a halogen work lamp, a 6″ machine vise, operating tools and an operator manual.
| Surface of Table (MM) | 800×175 | 900×200 | 1050×250 | 1200×275 | 1300×300 |
| No. of T-Slots | 3 | 3 | 3 | 3 | 3 |
| Size of T-Slots | ½” | ½” | ½” | ½” | ½” |
| Swivel either Side of Table | 45 | 45 | 45 | 45 | 45 |
| Cross Traverse (MM) | 150 | 150 | 175 | 200 | 250 |
| Vertical Traverse (MM) | 400 | 400 | 450 | 500 | 625 |
| Longitudinal Traverse (MM) | 475 | 475 | 525 | 625 | 675 |
| Arbour Diameter (MM) | 25.4 | 25.4 | 25.4 | 25.4 | 25.4 |
| Taper of Spindle | ISO 40 | ISO 40 | ISO 40 | ISO 40 | ISO 40 |
| No. of Spindle Speed | 6 | 6 | 9 | 9 | 9 |
| Range of Spindle Speed (RPM) | 40 – 700 | 40 – 700 | 40 – 700 | 40 – 700 | 40 – 700 |
| Spindle Diameter (MM) | 50 | 70 | 80 | 80 | 90 |
| No of Feed in Longitudinal Table Long. | 2 | 2 | 2 | 3 | 3 |
| Main Motor Power (HP) | 1 | 1.5 | 2 | 2 | 2 |
| Weight (Kgs.) | 450 | 700 | 900 | 1300 |
