Visualisation of Flow Fields

Product Code LTEKCTLB-FMT61-0077

Description & Specification

Visualisation of Flow Fields

Visualisation of flow fields by using electrolytically generated hydrogen bubbles

Various models are included: aerofoil, rectangle, straight plate, curved plate, cylinder (various sizes), various models for changes in cross section

Flow straightener and glass balls ensure consistent and low-turbulence flow

Platinum wire as cathode and stainless steel plate as anode for electrolysis

Shallow water channel fitted with indirect led illumination along the experimental section

Setting power (with display), pulse and pause length of the power and the flow velocity in the water channel

Different flow velocities via variable-speed circulating pump.

Technical data

Pump with adjustable speed

Max. Flow rate: 20l/min

Generator for generation of bubbles

Pause: 8,4…1800ms

Impulse: 8,4…1800ms

Current: 0…200ma

3 cathodes with platinum wire

Anode, stainless steel plate, l-shaped

Water channel: approx. 6l

Diameter: 0,2mm

Length: 30, 50, 75mm

Experimental section: lxwxh: 550x150x50mm

Illumination: white leds on the side walls of the water channel

Dimensions and weight

Lxwxh: 410x400x170mm (display and control unit),

Lxwxh: 900x300x220mm (experimental unit)

Weight: approx. 24kg.

Trusted Visualisation of Flow Fields Manufacturer & Supplier

LTekOnline are the manufacturers of Visualisation of Flow Fields used to demonstrate engineering principles in Engineering Colleges, Engineering Schools, and Fluid Mechanics Teaching Equipment for Engineering Teaching Lab in Universities. We supply Visualisation of Flow Fields to TVET institutes, vocational training centres, polytechnics and research labs across more than 90 countries, with quality testing technology, comprehensive operation manuals and full after-sales support.

Manufactured to international standards

Detailed operation & experiment manuals

Turnkey lab installation & training

Worldwide shipping & on-site support
