Eyepiece: Widefield 10x/20mm focusable eyepieces with foldable rubber eye guards, antifungal. Accepts 26mm reticle.
Nosepiece: Reverse angle quadruple nosepiece (Ball bearing type) with click stops and rubber grip
Stand: Single mold aluminum stand with hand rests for enhanced comfort and stability
Viewing Bodies: Binocular head, 30° inclined, 360° rotatable, Interpupillary distance 48 - 75mm
Condenser: Sub stage Abbe condenser NA 1.25 with aspheric lens. Iris diaphragm with blue daylight filter. Rack and pinion movements on stainless steel guides
Focusing: Coaxial coarse and fine focusing on ball drive system for smooth operation
Illumination: LED (built in rechargeable battery) illumination with variable illumination control. Up to 100,000 hours of LED life
Electrical: Universal input 100V - 240V AC, 50/60Hz. Built-in voltage stabilizer
Objectives: Series infinity corrected DIN Plan Achromatic objectives 4x, 10x, 40x (spring loaded), 100x (spring loaded, oil), antifungal
Mechanical stage: Rackless X axis, double plate stage size 200 x 160mm, X/Y travel range 78mm x 54mm. Low drive right hand movement controls. Hard coated surface for scratch resistance. Double specimen holder clip
