Digital Monocular Microscope, 400x Digital Microscope

Product Code LTEKCTPH-83-86076

Description & Specification

Digital Monocular Microscope, 400x Digital Microscope Lab Equipment Suppliers in India

Enquire Now Print Page

Categories: School Microscope

Tags: Digital Monocular Microscope 400x Digital Microscope

Technical Specifications

Forwarded quadruple revolving nosepiece on ball-bearings
Achromatic 4x, 10x, S40x objectives
Secured DIN WF 10x/18 mm eyepiece with pointer
Coaxial coarse and fine adjustments with 200 graduations.
Precision 12.5 μm, 2.5 mm per rotation.
Monocular head, 45° inclined, 360° rotatable
Built-in 5 MP CMOS camera with USB-2 interface, 2560 x 1920 pixels
Supplied with Image Focus software
Plain 123 x 119 mm stage with 2 object clamps
Height adjustable Abbe condenser N.A. 1.25 with iris diaphragm and filter holder
1 W LED illumination with internal power supply 100-240 V (CE)
Supplied with power cord and dust cover in styrofoam case
All optics are anti-fungus treated and anti-reflection coated for maximum light throughput
Total travel approximately 15 mm. Friction adjustment

Microscope School Lab Equipment Suppliers in India

Why choose LTekOnline

Trusted Digital Monocular Microscope, 400x Digital Microscope Manufacturer & Supplier

LTekOnline are the manufacturers of Digital Monocular Microscope, 400x Digital Microscope used to demonstrate engineering principles in Engineering Colleges, Engineering Schools, and School Microscope for Engineering Teaching Lab in Universities. We supply Digital Monocular Microscope, 400x Digital Microscope to TVET institutes, vocational training centres, polytechnics and research labs across more than 90 countries, with quality testing technology, comprehensive operation manuals and full after-sales support.
