Cake and Depth Filtration

Product Code LTEKCTLB-FMT61-00115

Description & Specification

Cake and Depth Filtration

The unit shall perform the following experiments and investigations:

Learning Objectives / Experiments:

Fundamentals of filtration: Darcy’s equation

Identification of characteristic filtration values Balance

Depth filtration with different bulk solids and suspensions

Cake filtration with different suspensions.

Specification:

Filter element with sintered filter medium on its bottom to capture the particles

Flow meter with needle valve for adjustment

Pressure loss measurement with twin tube manometers

Fundamentals of cake and depth filtration

Height-adjustable filler hopper made of duran glass.

Technical Data Filter element

Inside diameter: approx. 37mm

Cross-sectional area: approx. 11cm²

Filter chamber height: 85mm

Tube material: duran glass

Pore size: 100µm

Thickness: 2mm

Filter medium, sintered filter sika 100

Material: sintered metal measuring ranges

Pressure: 2x 0…500mmwc

Temperature: -10…100°c

Flow rate: 40…360ml/min

Measuring cups

1x 100mL, scale division: 2mL

1x 1000mL, scale division: 10mL

Material of construction: stainless steel

Dimensions and Weight LxWxH: 450x410x1040mm

Weight: approx. 30kg.
