Calibrating a Pressure Sensor

Product Code LTEKCTLB-FMT61-0078

Description & Specification

Calibrating a Pressure Sensor

Enquire Now Print Page

Categories: Fluid Mechanics Teaching Equipment

Tags: Calibrating a Pressure Sensor

Technical Specifications

Calibration unit with dead-weight piston manometer and hand-operated spindle

Additional pressure sensor as cutaway model

Set of weights

Transmission medium: hydraulic oil

Electronic pressure sensor with ceramic measuring cell, integrated amplifier and voltage output

Digital display for output signal

Process schematic on front panel.

Technical data

Pressure sensor

Measuring range: 0…2,5bar

Output signal: 0…10vdc

Supply: 24vdc

Piston manometer with pressure piston

Pressure graduations: 0,5 – 1,0 – 1,5 – 2,0 – 2,5bar

Digital display: 4 1/2 digits

Hydraulic oil: HLP ISO 32

Diameter: 12mm

Number of weights: 5

Dimensions and Weight

LxWxH: 600x450x450mm

Weight: approx. 20kg.
