Objectives: Achromatic 4x/0.10, 10x/0.25 and S40x/0.65
Stage: 115 x 100 mm stage with integrated 55 x 20 mm X-Y mechanical stage
Viewing Head: Binocular with 45° inclined tubes or Trinocular with 30° inclined tubes Adjustable interpupillary distance 48-75 mm and ±5 diopter adjustment on left tube
Eyepieces: Wide field WF 10x/18 mm eyepieces, Eyepieces can be secured to prevent tampering
Nosepiece: Revolving nosepiece for four reversed objectives on ball bearings
Focusing: Coaxial coarse and fine adjustments, 200 graduations, 15 µm per graduation, 3 mm per rotation, total travel approximately 15 mm. Supplied with an adjustable rack stop to prevent damage to sample and objectives. The coarse adjustment is equipped with friction control
Illumination: 1W illumination, internal rechargeable batteries with an external 100-240 V battery charger/main adapter
Condenser: Height adjustable Abbe condenser N.A. 1.25 with iris diaphragm and filter holder

Microscope School Lab Equipment Suppliers in India

Ltekonline are the manufacturers of LED Microscope, Mechanical Stage, Rechargeable Student Microscope used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and School Microscope for Engineering Teaching Lab in Universities
