Drying Using Spray Dryer

Product Code LTEKCTLB-TTE60-0099

Description & Specification

Drying Using Spray Dryer

Enquire Now Print Page

Categories: Thermal Training Equipment

Tags: Drying Using Spray Dryer

Technical Specifications

Technical Specifications:

Framework of AISI 304 stainless steel with castors

Touch screen control panel

Built-in compressor

Temperature programmable up to 250°C

Variable speed fan

Drying chamber of borosilicate glass with vessel of borosilicate glass for collecting bottom product

Atomization system with spray nozzle of stainless steel and cleaning device

Cyclone of borosilicate glass with bottle of borosilicate glass for collecting the sample

Heating system of 3000 W

Peristaltic pump adjustable up to 1500 ml/h

Exhaust pipe for exhausted vapours

Power supply: 230Vac 50 Hz single-phase – 3 kVA

Dimensions: 780 × 560 × 1300 mm

Weight: 110 kg.

Why choose LTekOnline

Trusted Drying Using Spray Dryer Manufacturer & Supplier

LTekOnline are the manufacturers of Drying Using Spray Dryer used to demonstrate engineering principles in Engineering Colleges, Engineering Schools, and Thermal Training Equipment for Engineering Teaching Lab in Universities. We supply Drying Using Spray Dryer to TVET institutes, vocational training centres, polytechnics and research labs across more than 90 countries, with quality testing technology, comprehensive operation manuals and full after-sales support.
