Heat Conduction in Fluids

Product Code LTEKCTLB-TTE60-0080

Description & Specification

Heat Conduction in Fluids

Learning Objectives / Experiments

Steady heat conduction in gases and liquids:

Determination of thermal conductivities k for different fluids at different temperatures

Determine the thermal resistance of fluids

Transient heat conduction in fluids:

Introduction to transient heat conduction with the block capacity model

Interpret transient states during heating and cooling.

Specification:

Investigation of the thermal conductivity of common fluids, e.g. water, oil, air or carbon dioxide

Inner cylinder, continuously electrically heated

Water-cooled outer cylinder

Concentric annular gap between 2 cylinders containing the fluid being studied

Due to integrated microprocessor-based instrumentation no additional devices with error-prone wiring are required

Heating power: 350W

Height: 0,4mm

Temperature limitation: 95°C

Heat transfer area: 0,007439m² Annular gap

Average diameter: 29,6mm

Inner cylinder

Mass: 0,11kg

Specific heat capacity: 890J/kg-K

Measuring ranges:

Temperature: 2x 0…325°C

Heating power: 0…450W

Dimensions and Weight

LxWxH: 670x350x480mm

Weight: approx. 18kg

Material of construction: stainless steel
