Extended Surface Heat Transfer Module

Product Code LTEKCTLB-TTE60-0097

Description & Specification

Extended Surface Heat Transfer Module

The apparatus consists of a solid cylindrical matt black brass bar supported in a frame and heated at one end. At intervals from the heated end are eight thermocouples recording the surface temperature so that a temperature profile along the bar may be developed. An additional thermocouple records the ambient temperature.

The heater is located inside an insulated cylinder at one end of the apparatus. The heater input power is controlled through the variable 240v ac supply from the Heat Transfer Service Unit and is designed to operate at up to 20 Watts.

A small scale bench top accessory designed to measure the temperature profile and heat transfer along a horizontal extended surface (cylindrical pin). A small diameter uniform rod is heated at one end and heat flowing along the rod by conduction is lost to the surroundings by a combination of natural convection and radiation. The resulting heat transfer gives a temperature profile that may be investigated and predicted by conventional analysis.

All instrumentation and power supplies plug directly into the Heat Transfer Service Unit and readings are displayed on digital panel meters.

Trusted Extended Surface Heat Transfer Module Manufacturer & Supplier

LTekOnline are the manufacturers of Extended Surface Heat Transfer Module used to demonstrate engineering principles in Engineering Colleges, Engineering Schools, and Thermal Training Equipment for Engineering Teaching Lab in Universities. We supply Extended Surface Heat Transfer Module to TVET institutes, vocational training centres, polytechnics and research labs across more than 90 countries, with quality testing technology, comprehensive operation manuals and full after-sales support.

Manufactured to international standards

Detailed operation & experiment manuals

Turnkey lab installation & training

Worldwide shipping & on-site support
