Hydronic Balancing of Radiators Thermal Trainer

Product Code LTEKCTLB-TTE60-00120

Description & Specification

Hydronic Balancing of Radiators Thermal Trainer

Enquire Now Print Page

Categories: Thermal Training Equipment

Tags: Hydronic Balancing of Radiators Thermal Trainer

Technical Specifications

Variable pipework resistance

Preset thermostatic valve

Differential pressure relief valve

Balancing valve.

Specification:

Trainer for heating and plumbing

1 surface thermometer for temperature measurement at radiator inlets and outlets

Water connections using quick-release couplings, diameter inside 13mm, for optional connection to an external heating circuit

Expansion vessel, safety group, overflow valve

5 rotameters

6 radiators with thermostatic valve, bleed valve and adjustable lock shield valve.

Technical Data:

Pump

Power consumption: 60W

Max. head: 4m

Max. flow rate: 60L/min

6 balancing valves: PN 16

Measuring ranges

Temperature: 1x -50…300°C

Flow rate: 1x 30…320L/h, 4x 50…640L/h

Required for Operation

230V, 50Hz, 1 phase

Dimensions and Weight

LxWxH: 2.250x750x1.790mm

Weight: approx. 210kg.
