Heat Exchangers Study Bench

Product Code LTEKCTLB-TTE60-00103

Description & Specification

Heat Exchangers Study Bench

Enquire Now Print Page

Categories: Thermal Training Equipment

Tags: Heat Exchangers Study Bench

Technical Specifications

Equipment composition:

Aluminum profile frame structure, bottom with wanxiang wheel, flexible movement. Equipped with three heat exchangers, the stainless steel tank has the heating device and the cooling water system.

The bench allows:

The study of the operating of the exchangers in co-current and countercurrent modes.

The study of the heat balances.

The study of the performances of 3 exchangers’ types minimum.

The bench is composed of:

3 exchangers from different technologies.

Temperature measurement sensor.

Flow measurement sensor.

A hot water source.

A cold water source.

Temperature regulator.

The necessary accessories for the efficient functioning.

Power supply: 220V/380V/50Hz.

Experimental contents:

The characteristic experiment of pipe heat exchanger

The characteristic experiment of coil heat exchanger

The characteristic experiment of plate heat exchanger

Comparison of flow temperature of different heat exchangers.
