Boiling Heat Transfer Unit

Product Code LTEKCTLB-TTE60-0022

Description & Specification

Boiling Heat Transfer Unit

Enquire Now Print Page

Categories: Thermal Training Equipment

Tags: Boiling Heat Transfer Unit

Technical Specifications

Specification:

Evaporation with heating element

Condensation with tube coil

Safety valve protects against overpressure in the system

Pressure switch for additional protection of the pressure vessel, adjustable

Sensors for pressure, flow rate and temperature with digital display

Visualisation of boiling and evaporation in a transparent pressure vessel

Software for data acquisition via USB under Windows 7, 8.1, 10

Refrigerant R1233zd, GWP: 1.

Technical data:

Heater

Power: 250W, continuously adjustable

Safety valve: 2bar rel.

Pressure vessel: 2850mL

Condenser: coiled tube made of copper

Refrigerant: R1233zd

GWP: 1

Filling volume: 1,2kg

CO2-equivalent: 0t

Measuring ranges:

Pressure: 0…4bar abs. (tank)

Power: 0…300W (heater)

Flow rate: 0,05…1,8L/min (cooling water)

Temperature: 4x 0…100°C

230V, 50Hz, 1 phase

230V, 60Hz, 1 phase

120V, 60Hz, 1 phase

Dimensions and weight:

LxWxH: 1000x550x800mm

Weight: approx. 65kg
