Heat Transfer in Forced Convection

Product Code LTEKCTLB-TTE60-0077

Description & Specification

Heat Transfer in Forced Convection

Enquire Now Print Page

Categories: Thermal Training Equipment

Tags: Heat Transfer in Forced Convection

Technical Specifications

Objective:

Comparison Of Heat Transfer Coefficient For Different Airflow Rates And Heat Flow Rates

To Plot Surface Temperature Distribution Along The Length Of Pipe

To Determine Average Surface Heat Transfer Coefficient For A Pipe By Forced Convection

Utilities Required:

Table For Set-Up Support, control panel, instruction manual in English and other accessories

Electricity Supply: 1 Phase, 220 V Ac, 2 Amp

Technical Details:

Air Flow Measurement: Orifice Meter & Manometer

Control Panel Comprising Of

Digital Voltmeter: 0-300 Volt

Digital Ammeter: 0-2 Amp

Variac: 0-230 V, 2 Amps

Test Section : Horizontal, Externally Heated

Diameter: 28 Mm (Approx.)

Length: 400 Mm (Approx.)

Blower: Fhp Of Standard Makes

Heater: Nichrome Wire

Digital Temp. Indicator: 0-3000c, With Multi-Channel Switch

Temperature Sensors: Rtd Pt-100 Type

With Standard Make On Off Switch, Mains Indicator Etc.
