Tenders Description & Specification for Hydraulic Guillotine Shearing Machine
Hydraulic Guillotine Shearing Machine
Guillotine Type Hydraulically Variable rake angle design.
Better Cutting accuracy in thin sheets at lower rake angle with twist free cuts.
The stable robust ultrasonically tester IS 2062 grade welded structure.
Rigid box Type structure with inclined member for Ram & Table.
Less power consumption.
Hydraulic & Electrical Safety interlocks for overloading.
Better Safety for operator and machine.
Fast Production on smaller jobs.
NC up-gradation available.
Low noise & smooth operation gives higher efficiency of Operator.
Higher cutting capacity at higher rake angle
| ngth Cutting | Shearing Capacity Nominal Rake Angle | Nominal Rake Angle | Rake Angle range | Rake Angle Stroke per min | No. of Hold downs | Holding Force | Power | Packing Dimension (LXWxH) in mm | ||||||||
| Thickness in mm | in degree | in degree | Min. | Max. | in Kg. | in HP | ||||||||||
| M.S. | S.S | |||||||||||||||
| 2 | 2 | 0.6 | 0.6 | 1° | 1° | 30 | 30 | _ | 3 | 2000x1000x1250 | ||||||
| 2 | 2 | 0.6 | 0.6 | 1° | r | 25 | 25 | _ | _ | 3 | 2500x1250x1500 | |||||
| 2 | 2 | 0.6 | 0.6 | 1° | r | 20 | 20 | 3 | 3000x1250x1850 | |||||||
| 3.15 | 4 | 2 | 3.15 | 1°15′ | 0.5-3° | 21 | 9 | 16 | 2600 | 5 | 3700x1400x2100 | |||||
| 3.15 | 4 | 2 | 3.15 | 1°15′ | 0.5-3° | 12 | 6 | 20 | 3200 | 7.5 | 4700x1500x2250 | |||||
| 4 | 6 | 3 | 4 | 1°37′ | 0.5-3° | 10 | 3 | 24 | 15000 | 10 | 5700x1700x2750 | |||||
| 4 | 6 | 3 | 4 | 1°37′ | 0.5-3° | 10 | 3 | 28 | 15000 | 10 | 6700x1800x2850 | |||||
Ltekonline are the manufacturers of Hydraulic Guillotine Shearing Machine used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and Workshop Machines for Engineering Teaching Lab in Universities
