Installations Electrical Testing

This program includes the analysis of installations such as:
Lighting and EMF distribution systems
with energy counter (kWh)
Staircase lighting system
Interphone system
Earthing and equipotential system
TV antenna system
Telephone distribution system
Gas and CO alarm system
Anti theft system
ADDITIONAL TRAINING PROGRAM THAT CAN BE IMPLEMENTED:
Video interphone system
Consumption optimization system
Automatic lighting system with sensor
Telephone system
Electric separation with isolation transformer
Home automation systems with PLC
Lighting control with intelligent BUS systems.
TECHNICAL SPECIFICATIONS:
This unit is made of welded sheet steel and sections, chemically treated and painted with several coats of epoxy varnish. Each one of the 4 available walls is provided with a panel including junction
boxes housing the components of the concerned system.
The whole framework is laid on a movable wheeled base.
Wall 1 (main entrance):
1 main power supply of 230 V – 16 A
1 single-phase energy meter of 230 V – 20A
1 branch exchange with 2 differential circuit breakers and 3 magneto-thermal circuit breakers
1 antenna control unit with mixer amplifi er, 4-output divider and 7 TV sockets
1 TV antenna installed on the roof (III – IV – V band)
1 interphone power supply unit with changeover switch for excluding the outdoor unit
1 two-button interphone porter
1 electric lock
1 lighting nameplate with pushbutton
1 earth collector for connecting earthing plates and equipotential node
4 earthing connections with resistance of 1 Ω and breaking terminals
1 two-zone anti theft control unit
1 electronic self-powered siren
