Laminar Flow Visualization Unit

Product Code LTEKCTLB-FMT61-00100

Description & Specification

Laminar Flow Visualization Unit

Enquire Now Print Page

Categories: Fluid Mechanics Teaching Equipment

Tags: Laminar Flow Visualization Unit

Technical Specifications

Technical data:

Pump with adjustable speed

Max. flow rate: 20L/min

Bubble generator

Pause: 8,4…1800ms

Pulse: 8,4…1800ms

Current: 0…200mA

3 cathodes with platinum wire

Length: 30, 50, 75mm

Anode, stainless steel plate, L-shaped

Diameter: 0,2mm

Water channel: approx. 6L

Illumination: white LEDs on the side walls of the water channel

Dimension (approx.): LxWxH: 900x300x220mm (experimental unit) Weight: approx. 24kg

Related experiment

Visualisation of streamlines for flow incident to a weir

Visualisation of streamlines when flowing around various drag bodies

How differently shaped weirs affect the flow.
