Mechanical Heat Pump Study Unit

Product Code LTEKCTLB-TTE60-00100

Description & Specification

Mechanical Heat Pump Study Unit

To Study the Mechanical heat pump and find its COP 0.3-0.5 TR

Condenser: – Water immersed/cooled type, shell and heat coil heat exchanger.

Evaporator: – Water immersed/cooled type, shell and heat coil heat exchanger.

Compressor: – Hermetically sealed compressor with its standardized electrical accessories.

Water pump: – Two nos. One for condenser, 2nd for evaporator, which shall be connected separately for both rotameter.

Main switch , Voltmeter-Digital Type, Amp Meter-Digital Type, Switches, Indication Lights, Energy-Meter for Compressor Input, Suction gauge for flow Pressure Measurements, Discharge gauge for High Pressure Measurement, Capillary Tube, Expansion Device, Drier, Gas Charging Valve.

Provided with selector switch for various temperature applications

Glass Tube Rotameter to measure the flow of liquid refrigerant: – One in No

Glass Tube Rotameter to measure the water flow rate: – Two Nos. (One for Condenser water and second for Evaporator water circulations

To study all components used in mechanical heat pump system

To study the mechanical heat pump cycle

Voltage: – Single Phase 220 Volts 50 Hz

Refrigerant: – Freon – 134 A.

Trusted Mechanical Heat Pump Study Unit Manufacturer & Supplier

LTekOnline are the manufacturers of Mechanical Heat Pump Study Unit used to demonstrate engineering principles in Engineering Colleges, Engineering Schools, and Thermal Training Equipment for Engineering Teaching Lab in Universities. We supply Mechanical Heat Pump Study Unit to TVET institutes, vocational training centres, polytechnics and research labs across more than 90 countries, with quality testing technology, comprehensive operation manuals and full after-sales support.
