Eyepieces: WF10x/18.5mm field of view, with pointer eyepiece is locked-in to prevent classroom tampering and accept 19mm reticles
Nosepiece: Rear facing, quadruple, ball bearing with positive click stops to ensure parcentration
Optical System: DIN Optical System, f=160mm, Anti-Mold
Viewing Head: Monocular; Inclined 30° and rotatable 360°; Vertical camera port with photo tube (c-mount adapter sold separately)
Objectives: Achromat 4x, 10x, Semi-Plan 40xR* and 100xR oil* - (*spring-loaded).
Condenser: N.A. 1.25 Abbe condenser on rack and pinion with iris diaphragm and swing-out filter holder
Stand: Cast alloy aluminum; built-in fixed focus stop allows for rapid focusing while protecting specimens; built-in carry handle and cord hanger
Stage: Rackless Mechanical Stage; size 150mm x 139mm; travel area 75mm (X) x 32mm (Y) movement with right hand control; vernier scale reading to 0.1mm
Illumination: Variable LED illumination; bulb life rated for 20,000 hours; UL approve
Focusing System: Coaxial coarse and fine focus controls with an adjustable tension control; all metal gears
Accessories: Dust cover, immersion oil and instruction manual included
Dimensions (LxWxH): 255mm x 198mm x 368mm

Microscope School Lab Equipment Suppliers in India

Ltekonline are the manufacturers of Monocular LED Microscope with Vertical Camera Port Student Microscope used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and School Microscope for Engineering Teaching Lab in Universities
