Monocular LED Microscope with Vertical Camera Port Student Microscope

Eyepieces: WF10x/18.5mm field of view, with pointer eyepiece is locked-in to prevent classroom tampering and accept 19mm reticles
Nosepiece: Rear facing, quadruple, ball bearing with positive click stops to ensure parcentration
Optical System: DIN Optical System, f=160mm, Anti-Mold
Viewing Head: Monocular; Inclined 30° and rotatable 360°; Vertical camera port with photo tube (c-mount adapter sold separately)
Objectives: Achromat 4x, 10x, Semi-Plan 40xR* and 100xR oil* - (*spring-loaded).
Condenser: N.A. 1.25 Abbe condenser on rack and pinion with iris diaphragm and swing-out filter holder
Stand: Cast alloy aluminum; built-in fixed focus stop allows for rapid focusing while protecting specimens; built-in carry handle and cord hanger
Stage: Rackless Mechanical Stage; size 150mm x 139mm; travel area 75mm (X) x 32mm (Y) movement with right hand control; vernier scale reading to 0.1mm
Illumination: Variable LED illumination; bulb life rated for 20,000 hours; UL approve
Focusing System: Coaxial coarse and fine focus controls with an adjustable tension control; all metal gears
Accessories: Dust cover, immersion oil and instruction manual included
Dimensions (LxWxH): 255mm x 198mm x 368mm
