Training System: Level Control

Product Code LTEKCTLB-FMT61-0080

Description & Specification

Training System: Level Control

Enquire Now Print Page

Categories: Fluid Mechanics Teaching Equipment

Tags: Training System: Level Control

Technical Specifications

Experimental unit for control engineering experiments

Disturbance variables generated by electromagnetic proportional valve in tank outlet

Tank with overflow and graduated scale

Level control process with transparent tank

Process schematic on front panel

Speed-controlled pump

Level measurement by pressure sensor.

Technical Data:

Level-controlled tank

Capacity: 1200mL

Storage tank

Capacity: 3700mL

Pump

Max. Flow rate: 8L/min

Max. Head: 6m

Proportional valve: Kvs: 0,7m³/h

Power consumption: 18W

Pressure sensor: 0…30mbar (0…300mm)

Process schematic with controller type selection (manual, continuous controller, two- or three-point controller, programmer)

Time functions

Simulation function

Disturbance variable input

Dimensions and Weight

LxWxH: 600x450x800mm.
