Two Stage Compressor

Principle introduction:

It converts the supplied mechanical energy into a higher air pressure. Compressed air generation systems are used to drive machines in mining, for pneumatic control systems in assembly plants or tyre inflation systems at petrol stations. Compressed air for industry and businesses that use compressed air as an energy source is generated by means of so-called compressed air generation systems. A key component of these systems is the compressor. Safety valves and a pressure switch complete the system. Sensors measure the pressures and temperatures in both stages as well as the electric power consumption. A nozzle at the intake vessel serves to determine the intake volumetric flow rate. The measured values can be read on digital displays. The air is sucked into the intake vessel and calmed there before it is compressed in two stages. The additional pressure vessel for intercooling is located between the first and second stage. After the second stage, the compressed air is pressed into another pressure vessel through a cooling tube. To achieve a steady state, the compressed air can be released through a blow-off valve with silencer.

Equipment composition:

The two-stage piston compressor is fixed in the frame with three cylinders and a cooling water system. Aluminum profile frame structure, bottom with universal wheel, flexible movement.

Experimental contents:

The temperature pressure contrast of the first – and second-order compression.

The bench allows the study of the thermodynamic aspects relative to the two-stage compressor.

Thermodynamic experiments of two – stage compressors.

The bench is composed of:

Alternative compressor.

Two-stage piston compressor.

Air flow rate: from 100L/min.

Reservoir capacity: 200L minimum.

Maximum pressure: 10 bars minimum.

2 air-water exchangers for the two stages, with possibility of choosing co-current or countercurrent exchange.

Measurement sensors:

Thermocouples for measuring air and water temperatures at different points.

Manometers for measuring the aspiration and the discharge pressures in each stage.

Flow rate sensor for measuring the cooling water flow rate.

Air flow measurement sensor.

All the necessary accessories assuring the efficient functioning.

Power supply: 220V/380V/50Hz.
