Cross-Flow Heat Exchanger

Product Code LTEKCTLB-TTE60-0085

Description & Specification

Cross-Flow Heat Exchanger

Enquire Now Print Page

Categories: Thermal Training Equipment

Tags: Cross-Flow Heat Exchanger

Technical Specifications

Clear experimental set-up for demonstrating the Fundamental principles of heat transfer1

Processing of measured data on a PC1

Technical Description

The experimental unit mainly includes a vertical air Duct. The following heater elements are included: Pipe, pipe bundle and finned pipe. To investigate the Effect of the flow in the pipe bundle, the heater insert Can be positioned in different pipe rows. A fan draws the air through the duct. Interchangeable heaters dissipate heat directly into the Airflow. Electronic sensors are used to take measurements.

The measured values are indicated digitally on the Learning Objectives / Experiments

Investigation of convection processes

Comparison of heat transfer for different heating

Elements

Demonstration of the relationship between heat

Comparison between different heating elements

Transfer, area of heat transfer and flow velocity.
