Domestic Gas Supply Training Panel

Product Code LTEKCTLB-TTE60-00118

Description & Specification

Domestic Gas Supply Training Panel

Enquire Now Print Page

Categories: Thermal Training Equipment

Tags: Domestic Gas Supply Training Panel

Technical Specifications

Learning Objectives / Experiments:

Testing before and after gas connection in accordance with regulations

Simulation of different leaks

Demonstration of leak detection

Working on gas pipes.

Specification:

Exercises on gas pipes

1 pipe section as supply pipe with gas socket and gas connection with ball valve

2 individually selectable pipe sections

1 pipe section for finding leaks

1 gas meter with 1 connection

1 gas meter with 2 connections

Technical Data:

Gas pressure controller

Admission pressure: 350mbar

Outlet pressure: 20mbar

Leak testing device: max. 500mmWC

Air pressure controller

Max. inlet pressure: 21bar

Outlet pressure: 0.01…0.6bar

Dimensions and Weight

L x W x H: 1650 x 200 x 1100 mm (panel)

Weight: approx. 50 kg (panel).
