Radiator Training Panel Heat Transfer Trainer

Product Code LTEKCTLB-TTE60-00121

Description & Specification

Radiator Training Panel Heat Transfer Trainer

Enquire Now Print Page

Categories: Thermal Training Equipment

Tags: Radiator Training Panel Heat Transfer Trainer

Technical Specifications

Learning Objectives / Experiments

Determination of the heat emitted

Determination of pipework characteristics for different operating conditions

Hydronic balancing of radiators

In conjunction with other training panels, it is possible to set-up a complete heating system.

Trainer on heating systems and plumbing

2 cooling water connections

5 rotameters

2 water connections for boiler

4 radiators with thermostatic valve, air bleed and adjustable lock shield valve

Water connections made using quick-release couplings.

Technical Data:

Radiator

Plate heat exchanger with 10 plates

Capacity: 3kW

Measuring ranges

Flow rate: 1x 0…1000L/h, 4x 0…300L/h

Dimensions and Weight

L x W x H: 1650 x 350 x 1100 mm (panel)

Weight: approx. 60 kg (panel).
