Shell & Tube Heat Exchanger
Description & Specification
Shell & Tube Heat Exchanger
Categories:
Thermal Training Equipment
Technical Specifications
The shell and tube heat exchanger consists of seven tubes, surrounded by a transparent outer shell. The hot water flows through the tube space and the cold water through the space in The shell. Part of the thermal energy of the hot water is transferred to the cold water. Baffle plates are used to deflect the flow in the shell in such a way as to create greater turbulence and thus a more intensive transfer of heat. Flows in a cross-flow.
Shell and tube heat exchangers are used in widespread use. The main advantages of this design are the large heat transfer surface and the compact design. Shell and tube heat exchangers are used in the chemical and pharmaceutical industries, in refineries and in process engineering plants.
The Shell and tube heat exchangers is part of a series of units enabling experiments to be performed on different heat exchanger types. The experimental unit is ideally suited for investigating the functioning and behaviour of a shell and tube heat exchanger in operation.
Valves on the supply unit are used to adjust the flow rates of hot and cold water. The supply hose can be reconnected using quick-release couplings, allowing the flow direction to be reversed. This allows cross parallel flow or cross counterflow operation. For measuring the inlSTand outlST temperature are located at the supply connections.
During experiments, temperature curves are plotted and displayed graphically.
Technical details:
Specification
Cross parallel flow and cross counterflow operation possible
Transparent shell, visible tube bundle
Tube bundle consisting of 7 tubes and 4 baffle plates
Technical data
Heat transfer surface: 200cm2
Tube bundle, stainless steel
Outer diameter: 6mm
Wall thickness: 1mm
Tubes, 7
Shell, transparent (PMMA)
Outer diameter: 50mm
Wall thickness: 3mm.
